Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
28
2.5.2 Vertical Pole
The mounng kit can be used on a thin, medium, or thick pole.
Thin Pole
Dia. 3/4” ‐1 1/2”
Medium Pole
Dia. 2 ‐ 3
Thick Pole
Dia. > 3

1. Diameter 3/4” to 1 1/2” (2cm to 4cm): Posion the pole clamp as shown in the following gures. Do not
ghten the bolts all the way.
Figure 35: Connect Pole Clamp to Radio Holder
Figure 36: Parally ghten bolts
2. Place this assembly on the pole where you want to mount the device. Once it is in place, rotate the pole
clamp as shown, then ghten both bolts.
Figure 37: Rotate Clamp and ghten bolts
Figure 38: Completely ghten bolts

1. Diameter 2” to 3” (5cm to 7.5cm): Posion the pole clamp as shown in the following gures. Do not
ghten the bolts all the way.
