• MulSector integrated radio units, whether base staon or antenna (if installing two units back‐to‐back,
See Mounng Back‐to‐Back MulSector Integrated Units on page 46)
• External PoEs
• RADWIN GSUs
• External antennas (with mounng kit adaptor)
The SU PRO/AIR EMB has its own mounng kit: See Install Mounng Kit for the SU PRO/ AIR EMB on page
33. The SU Connectorized is mounng using worm‐drive clamps: See Mounng the SU Connectorized on
page 50.
Figure 34: Mounng Kit Contents
Tighten all bolts with a torque of 15Nm.
The mounng kit can be used on a vercal or horizontal pole or on a wall:
Vercal Pole
Page 28
Horizontal Pole
Page 30
Wall
Page 32
