Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
106
Appendix E. Cered Antennas
E.1 For Deployment in US/Canada
Radio devices that bear the following FCC/IC IDs refer to Table 10 to Table 13 below:
Contains FCC ID: Q3K‐ 5XACMOLD Contains IC: 5100A‐ 5XACMOD
Only the antennas shown in the tables below or antennas of the same type with lower gain are approved
for use in this system. The antennas must be installed so as to provide a minimum separaon distance from
bystanders as specied in the tables below.
This radio transmier “Contains IC: 5100A‐5XACMOD” has been approved by Innovaon, Science and
Economic Development Canada to operate with the antenna types listed below, with the maximum
permissible gain indicated. Antenna types not included in this list that have a gain greater than the
maximum gain indicated for any type listed are strictly prohibited for use with this device.
The input impedance of all antennas is 50 Ohm.
Table 10: Frequency Band 5725‐5850 MHz
Cat. No.
Type
Gain (dBi)
Dir
BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
Integrated
Flat DP BS
11.0
120°
25
26
RW‐9061‐5004
Flat DP BS
11.0
120°
25
26
Integrated
Flat DP BS
12.0
95°
25
29
Integrated
Flat DP BS
13.0
90°
25
32
RW‐9061‐5001
Flat DP BS
14.0
90°
25
36
RW‐9061‐5002
Flat DP BS
15.5
60°
25
43
Integrated
Flat DP
16.0
35°
25
45
Integrated
Flat DP
16.5
35°
25
48
RW‐9613‐4960
Flat DP
23.0
8°
25
100
Integrated
Flat DP
23.5
8°
25
107
RW‐9622‐5001
Flat DP
29.0
5°
25
200
RW‐9401‐5002
Shark Fin SP
12.5
50°
25
30
RW‐9721‐5158
Dish DP
28.0
5.5°
25
178

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
