3.1.5 Internal ESD Protection circuits
RADWIN equipment is designed to meet the ETSI/FCC/Aus/NZ/CSA EMC and Safety requirements. To fulll
these requirements, the system's Telecom lines at the radio unit/PoE are Transformer‐isolated and include
internal ESD (Electro‐Stac‐Discharge) Protecon circuits.
When installing an AC powered SU: To maintain Overvoltage (Installaon)
Category II, install a suitable surge suppressor device in the branch circuit to limit
expected transients to Overvoltage Category II values.
The limits are based on IEC60664 and are also located in Table 2H of UL60950 (for
mains <= 150V, the transient rang is 1500V; for 150V < mains <= 300V, the
transient rang is 2500V; and for 300V < mains <=600V, the transient rang is
4000V).
3.1.6 Ratings
Table 3: RADWIN 5000 Model Rangs
Model Name
Input Voltage &
Current
Enclosure Type
Oper. Temp
RADWIN 5000 SFF
55VDC, 1A
IP67/Type 4
‐35C to +60C
RADWIN 5000 LFF
48‐57VDC, 1A
IP67/Type 4
‐35C to +60C
SU PRO/AIR EMB
24‐56VDC, 1A
IP66/Type 4
‐35C to +60C
SU Integrated & SU PRO
INT 3.x
24‐56VDC, 1A
IP67/Type 4
‐35C to +60C
RADWIN 5000 JET
55VDC, 0.5A
IP67/Type 4
‐35C to +60C
JET‐DUO 3/5 GHz
55VDC, 0.5A
IP67/Type 4
‐35C to +60C
JET PRO
55VDC, 0.5A
IP67/Type 4
‐40C to +60C
MulSector Base
Staon
57VDC, 0.7A
IP67/Type 4
‐35C to +60C
NEO
42‐57V
IP67/Type 4
‐40C to +60C
NEO DUO
42‐57V
IP67/Type 4
‐40C to +60C
JET‐AIR
42‐57V
IP67/Type 4
‐40C to +60C
