Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
119
Operang Form
Gain (dBi)
Dir BW
Tx Power per chain
(dBm)
Min. Safe
Distance (cm)
Uniform
20.0
9.4
7
20
Floodlight
11.0
60
16
20
Table 38: Frequency Band 5725‐5875 MHz
Operang Form
Gain (dBi)
Dir BW
Tx Power per chain
(dBm)
Min. Safe
Distance (cm)
Uniform
20.0
9.4
13
20
Floodlight
11.0
60
22
20
Table 39: Frequency Band 3400‐3800 MHz
Operang Form
Gain (dBi)
Dir BW
Tx Power per chain
(dBm)
Min. Safe
Distance (cm)
Uniform
17.0
17
30
81
Floodlight
9.0
70
30
32
The SU Integrated must be installed so as to provide a minimum separaon distance from bystanders as
specied in the tables below:
Table 40: Frequency Band 5725‐5875 MHz
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min Safe
Distance (cm)
RW‐9401‐5007
Omni
10
360°
23.0
20
RW‐9105‐5159
Flat DP
13
30°
20.0
20
RW‐9105‐4958
Flat DP
16
20°
17.0
20
Integrated
Flat DP
22
10°
11.0
20
RW‐9613‐4960
Flat DP
23
10°
10.0
20
Table 41: Frequency Band 5470‐5725 MHz
