Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
121
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per chain
(dBm)
Min Safe
Distance (cm)
Integrated
Flat DP BS
13.0
90°
20.0
20
RW‐9061‐5001
Flat DP BS
14.0
90°
19.0
20
RW‐9061‐5002
Flat DP BS
15.0
60°
18.0
20
RW‐9061‐5004
Flat DP BS
11.0
120°
22.0
20
RW‐9061‐5010
Flat DP BS
13.0
90°
20.0
20
RW‐9105‐4958
Flat DP
16.0
20°
17.0
20
RW‐9105‐5158
Flat DP
19.0
17°
14.0
20
RW‐9613‐4960
Flat DP
23.0
10°
10.0
20
RW‐9622‐5001
Flat DP
28.0
5°
5.0
20
RW‐9721‐5158
Dish DP
28.0
5.6°
5.0
20
RW‐9732‐4958
Dish DP
32.0
4°
1.0
20
Table 45: Frequency Band 5470‐5725 MHz
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min Safe
Distance (cm)
Integrated
Flat DP BS
13.0
90°
14.0
20
RW‐9061‐5001
Flat DP BS
14.0
90°
13.0
20
RW‐9061‐5002
Flat DP BS
15.0
60°
12.0
20
RW‐9061‐5004
Flat DP BS
11.0
120°
16.0
20
RW‐9061‐5010
Flat DP BS
13.0
90°
14.0
20
RW‐9105‐4958
Flat DP
16.0
20°
11.0
20
RW‐9105‐5158
Flat DP
19.0
17°
8.0
20
RW‐9613‐4960
Flat DP
23.0
10°
4.0
20
RW‐9622‐5001
Flat DP
28.0
5°
‐1.0
20
RW‐9721‐5158
Dish DP
28.0
5.6°
‐1.0
20
RW‐9732‐4958
Dish DP
32.0
4°
‐5.0
20
