Rational SCC Series

68
SCC
Edition 10-2008a
1 - DIAGNOSTIC
Cabinet B1
130°C 345°C
act max
2 - DIAGNOSTIC
Quenching B2
70°C 95°C
act max
5 - DIAGNOSTIC
Steam Generator B5
104°C 115°C
act max
4 - DIAGNOSTIC
Humidity B4
130°C 345°C
act max
3 - DIAGNOSTIC
not used
900°C 900°C
Diagnostic mode SCC
RESET
RESET
RESET
RESET
- Temp. range: -30 - 340°C (-22 - 644°F)
- 900°C (655°C until SW version 01-07-08)
broken thermocouple or loose plug
- act: actual temperature
- max: maximum recorded temperature
- to reset max value press RESET
- Temp. range: -30 - 340°C (-22 - 644°F)
- 900°C (655°C until SW version 01-07-08)
broken thermocouple or loose plug
- act: actual temperature
- max: maximum recorded temperature
- to reset max value press RESET
- B3 free, no function
- Temp. range: -30 - 340°C (-22 - 644°F)
- 900°C (655°C until SW version 01-07-08)
broken thermocouple or loose plug
- act: actual temperature
- max: maximum recorded temperature
- to reset max value press RESET
- Temp. range: -30 - 340°C (-22 - 644°F)
- 900°C (655°C until SW version 01-07-08)
broken thermocouple or loose plug
- act: actual temperature
- max: maximum recorded temperature
- to reset max value press RESET
RESET
