16 - Gas Hot Air Blower bottom
17 - Buzzer T2
18 - Interior Light H1
19 - Display lights
20 - Exhaust hood
21 - Sicotronic
Function test SCC
Function Test
1 - Steam (Dampf) 50%
not used in Gas units
2 - Steam (Dampf) 100%
3 - Hot Air 50%
Gas - burner top
4 - Hot Air 100%
Gas - burner bottom
5 - Fan motor top
6 - Fan motor bottom
7 - Solenoid valve  lling Y1
8 - SC Pump M4
9 - Solenoid quenching Y2
10 - Solenoid Moistening Y3
10.1 - Care valve and pump
Y4 + M12
11 - Humidity  ap motor M3
12 - CleanJet Pump M6
13 - Drain Valve Motor M7
14 - Gas Steam Blower
15 - Gas Hot Air Blower Top
