Rational SCC Series User Manual

171
Trouble shooting SCC
Edition 10-2008a
Buzzer sounds
Reason: Any thermocouple is defective
Different buzzer intervals depending which thermocouple is defective
Buzzer sounds for 30 seconds
after fault identi cation and every
time unit is switched on
YES
Indication Service 20?
Interior cabinet sensor B1
defective unit out of order
Change defective thermocouple
NO
NO
Check which ther-
mocouple shows actual
values > 654°C,
This indicates, that the corre-
sponding „Thermocouple is
broken“
Check connector of the thermo-
couple for suf cient contact
NO
Indication
CT probe defect?
Indication
Service 31.1 up to 31.6?
- More than 3 measuring points of the
probe are defective.
- SCC program‘s and manual
cooking program‘s with core
temperature can not be used
- Less than 3 measuring points of the
probe are defective
- SCC program‘s and manual
cooking program‘s with core
temperature are running on
emergency control
Activate diagnostic program
Step 1 - 11
YES
NO
YES
YES
Buzzer frequency by failure of thermocouple
(counting in 5 sec.)
B1 12 in 5 sec.
B2 6 in 5 sec.
B4 5 in 5 sec.
B5 8 in 5 sec.
Core temperature sensor 20 in 5 sec.
