Diagnostic mode SCC
17 - Clima Motor
M3 / S4
18 - Hot Air
19 - Steam
20 - SC Automatic
21 - Volume
22 - M6 CleanJet pump
Y2 - Quenching Solenoid
23 - M7 Drain valve
S12 Micro switch
23.1 M12 Care motor
Y4 Solenoid care
24 - Service Error history
25 - Gas Error history
DIAGNOSTIC
1 - Cabinet B1
2 - Quenching B2
3 - Not used B3
4 - Humidity B4
5 - Steam Generator B5
6-11 - Core Temp B6-11
12 - Temperature PCB
13 - Level Electrode S2
14 - Door Contact S3
15 - Clima
P1 - B4 - RPM
16 - Clima Status
16.1 - Cal.Geodat
Auto. Calibration
