Rational SCC Series

88
SCC
Edition 10-2008a
Function test SCC
- Electric units: Steam heating 50%;
- Gas units: not used
- Actual temperature of B5
Attention: Parts are not protected against overload!
- Electric and gas units: Steam heating 100%;
- Indication gas units (window 2): „Steam Gas-Burner“
- Actual temperature of B5
Attention: Parts are not protected against overload!
- Electric units: Hot air heating 50%;
- Gas units: Hot air heating 100%
- Indication window 2:
Table models: „Hot Air Gas-Burner“
Floor models: „Hot Air Gas-Top Burner“
- Actual temperature of B1
Attention: Parts are not protected against overload!
- Electric units: Hot air heating 100%
- Only gas oor models: Hot air heating 100%
- Indication window 2:
„Hot Air Gas-Bottom Burner“
- Actual temperature of B1
Attention: Parts are not protected against overload!
Fan motor top:
- Select RPM with central dial
(default: second highest RPM):
- Typ 61: 500,1100,1550,1650
- Typ 62, 101, 201: 500,1250,1800,1900
- Typ 102, 202: 550,1450, 2000, 2200
5 - Function Test
Fan motor top
Speed 3
1800rpm
actual speed
xxxx
4 - Function Test
Hot Air 100%
0 - 1
Temperature B1 185°C
3 - Function Test
Hot Air 50%
0 - 1
Temperature B1 185°C
2 - Function Test
Steam 100%
0 - 1
Temperature B5 103°C
1 - Function
Test
Steam 50%
0 - 1
Temperature B5 103°C
Start
Start
Start
Start
Start
