Rational SCC Series User Manual

89
SCC
Edition 10-2008a
Function test SCC
Fan motor bottom:
- Select RPM with central dial
(default: second highest RPM):
- Typ 61: 500,1100,1550,1650
- Typ 62, 101, 201: 500,1250,1800,1900
- Typ 102, 202: 550,1450,2000,2200
- Activat. of solenoid valve  lling Y1
- Level electrode shows 1 = steam generator lled
- Level electrode shows 0 = steam generator partial lled
- Activation of SC Pump M4
- Level electrode shows 1 = steam generator lled
- Level electrode shows 0 = steam generator partial lled
- Activation of solenoid valve quenching Y2
- Indication of actual temperature B2
(needed for testing quenching system).
- Activation of solenoid valve moistening Y3
10 - Function Test
Solenoid moistening Y3
0 - 1
9 - Function Test
Solenoid quenching Y2
1 - 0
Temperature B2 36°C
8 - Function Test
SC Pump M4
1 - 0
Level electrode 1 - 0
7 - Function Test
Solenoid valve  lling Y1
1 - 0
Level electrode 1 - 0
6 - Function Test
Fan motor bottom
Speed 4
1900rpm
actual speed
xxxx
Start
Start
Start
Start
Start
