Rational SCC Series User Manual

91
SCC
Edition 10-2008a
Function test SCC
Flue gas analysis Gas blower Hot air top:
Press START to operate hot air gas burner bottom;
- CO
2
adjustment with CO
2
screw at Max rpm
-
CO
2
cross checking at Min rpm
- Flame current should be always above 4,0 A,
ideally 5,0-5,75 A
Flue gas analysis Gas blower Hot air bottom:
Press START to operate hot air gas burner bottom;
- CO
2
adjustment with CO
2
screw at Max rpm
-
CO
2
cross checking at Min rpm
- Flame current should be always above 4,0 A,
ideally 5,0-5,75 A
Activation buzzer
Activation interior light
- Testing of all display lights by pushing and holding Start key.
The different lights will be activated in sequence.
19 - Function Test
Display light
18 - Function Test
Interior light
17 - Function Test
Buzzer T2
0 - 1
Gas Hot Air Blower Bot.
Max - Start - Min
CO2 FC rpm
xxx% 5,25A xxx
16 - Function Test
Gas Hot Air Blower Top
Max - Start - Min
CO2 FC rpm
xxx% 5,25A xxx
Start
Start
Start
Start
Start
