Reflex EZ-TRAC User Manual

MANUAL – REFLEX EZ-TRAC™ | 47
Select YES to continue to the MAIN menu. Note, the survey data will
be lost.
Select NO to return to the previous screen.
Figure 45 No Connection
The No Connection message appears if the
REFLEX™ EZ-COM unit
cannot establish a connection with the
REFLEX EZ-TRAC™.
Be sure to direct the IR port of the REFLEX™ EZ-COM unit to the IR
port of the
REFLEX EZ-TRAC™. Select RETRY to retry to connect to
the instrument.
Select CANCEL to cancel. The Cancel message as described above
will be displayed.
Figure 46 Serial Number Incorrect
Before downloading data, the
REFLEX™ EZ-COM unit verifies that the
serial number of the instrument is the same as the serial number of
the instrument that was initiated for the survey. If there is a mismatch,
the Serial number incorrect message appears.
Align the REFLEX™ EZ-COM unit with the correct instrument and select
RETRY.
Select CANCEL to cancel. The Cancel message as described above
will be displayed.
