RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 1033
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
(2) When AV
REF (+) = AVREFP/ANI0 (ADREFP1 = 0, ADREFP0 = 1), AVREF (−) = AVREFM/ANI1 (ADREFM = 1), target ANI
pin : ANI16 to ANI26 (supply ANI pin to EVDD0)
(T
A = −40 to +85°C, 1.6 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V, Reference voltage (+) = AVREFP,
Reference voltage (−) = AVREFM)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Resolution RES 8 10 bit
1.8 V ≤ VDD ≤ 5.5 V 1.2 ±5.0 LSB Overall error
Notes 1, 2
AINL
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V 1.2 ±8.5 LSB
3.6 V ≤ VDD ≤ 5.5 V 2.125 39
μ
s
2.7 V ≤ VDD ≤ 5.5 V 3.1875 39
μ
s
1.8 V ≤ VDD ≤ 5.5 V 17 39
μ
s
Conversion time tCONV
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V 57 95
μ
s
1.8 V ≤ VDD ≤ 5.5 V ±0.35 %FSRZero-scale error
Notes 1, 2
EZS
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±0.60 %FSR
1.8 V ≤ VDD ≤ 5.5 V ±0.35 %FSRFull-scale error
Notes 1, 2
EFS
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±0.60 %FSR
1.8 V ≤ VDD ≤ 5.5 V ±3.5 LSB Integral linearity error
Note 1
ILE
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±6.0 LSB
1.8 V ≤ VDD ≤ 5.5 V ±2.0 LSB Differential linearity error
Note 1
DLE
10-bit resolution
AV
REFP = VDD
1.6 V ≤ V
DD ≤ 5.5 V ±2.5 LSB
Reference voltage (+) AVREFP 1.6 VDD V
VAIN 0
AV
REFP
and
EV
DD0
V
Analog input voltage
V
BGR 2.4 V ≤ VDD ≤ 5.5 V 1.38 1.45 1.5 V
Notes 1. Excludes quantization error (±1/2 LSB).
2. This value is indicated as a ratio (%FSR) to the full-scale value.
