RL78/G13 CHAPTER 3 CPU ARCHITECTURE

R01UH0146EJ0100 Rev.1.00 122

Sep 22, 2011

Figure 3-13. Correspondence Between Data Memory and Addressing

(R5F100xC, R5F101xC (x = 6 to 8, A to C, E to G, J, L))

00000H

EFFFFH

F0000H

F0FFFH

F1000H

F7FFFH

F8000H

FFEDFH

FFEE0H

FFEFFH

FFF00H

FFFFFH

07FFFH

08000H

F07FFH

F0800H

Special function register (SFR)

256 bytes

General-purpose register

32 bytes

RAM

2 KB

Mirror

24 KB

Reserved

Special function register (2nd SFR)

2 KB

Reserved

Code flash memory

32 KB

Direct addressing

Based addressing

Based indexed addressing

Short direct

addressing

SFR addressing

FFF1FH

FFF20H

FFE1FH

FFE20H

Data flash memory

Note

4 KB

F1FFFH

F2000H

FF6FFH

FF700H

Reserved

Note R5F100xC only.

Caution When executing instructions from the RAM area while RAM parity error resets are enabled (RPERDIS

= 1), be sure to initialize the used RAM area + 10 bytes.
