RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 141
Sep 22, 2011
Table 3-5. SFR List (5/5)
Manipulable Bit Range Address Special Function Register (SFR) Name Symbol R/W
1-bit 8-bit 16-bit
After Reset
FFFD8H Priority specification flag register
02L
PR02L R/W
√ √
FFH
FFFD9H Priority specification flag register
02H
PR02H
PR02
R/W
√ √
√
FFH
FFFDAH Priority specification flag register
02L
PR03L PR03 R/W
√ √ √
FFH
FFFDCH Priority specification flag register
12L
PR12L R/W
√ √
FFH
FFFDDH Priority specification flag register
12H
PR12H
PR12
R/W
√ √
√
FFH
FFFDEH Priority specification flag register
13L
PR13L PR13 R/W
√ √ √
FFH
FFFE0H Interrupt request flag register 0L IF0L R/W
√ √
00H
FFFE1H Interrupt request flag register 0H IF0H
IF0
R/W
√ √
√
00H
FFFE2H Interrupt request flag register 1L IF1L R/W
√ √
00H
FFFE3H Interrupt request flag register 1H IF1H
IF1
R/W
√ √
√
00H
FFFE4H Interrupt mask flag register 0L MK0L R/W
√ √
FFH
FFFE5H Interrupt mask flag register 0H MK0H
MK0
R/W
√ √
√
FFH
FFFE6H Interrupt mask flag register 1L MK1L R/W
√ √
FFH
FFFE7H Interrupt mask flag register 1H MK1H
MK1
R/W
√ √
√
FFH
FFFE8H Priority specification flag register
00L
PR00L R/W
√ √
FFH
FFFE9H Priority specification flag register
00H
PR00H
PR00
R/W
√ √
√
FFH
FFFEAH Priority specification flag register
01L
PR01L R/W
√ √
FFH
FFFEBH Priority specification flag register
01H
PR01H
PR01
R/W
√ √
√
FFH
FFFECH Priority specification flag register
10L
PR10L R/W
√ √
FFH
FFFEDH Priority specification flag register
10H
PR10H
PR10
R/W
√ √
√
FFH
FFFEEH Priority specification flag register
11L
PR11L R/W
√ √
FFH
FFFEFH Priority specification flag register
11H
PR11H
PR11
R/W
√ √
√
FFH
FFFF0H
FFFF1H
Multiplication/division data register
A (L)
MDAL R/W
− − √
0000H
FFFF2H
FFFF3H
Multiplication/division data register
A (H)
MDAH R/W
− − √
0000H
FFFF4H
FFFF5H
Multiplication/division data register
B (H)
MDBH R/W
− − √
0000H
FFFF6H
FFFF7H
Multiplication/division data register
B (L)
MDBL R/W
− − √
0000H
FFFFEH Processor mode control register PMC R/W
√ √ −
00H
Remark For extended SFRs (2
nd
SFRs), see Table 3-6 Extended SFR (2
nd
SFR) List.
