RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 143
Sep 22, 2011
Table 3-6. Extended SFR (2
nd
SFR) List (1/8)
Manipulable Bit Range Address Special Function Register (SFR) Name Symbol R/W
1-bit 8-bit 16-bit
After Reset
F0010H A/D converter mode register 2 ADM2 R/W
√ √ −
00H
F0011H Conversion result comparison
upper limit setting register
ADUL R/W
− √ −
FFH
F0012H Conversion result comparison
lower limit setting register
ADLL R/W
− √ −
00H
F0013H A/D test register ADTES R/W
− √ −
00H
F0030H Pull-up resistor option register 0 PU0 R/W
√ √ −
00H
F0031H Pull-up resistor option register 1 PU1 R/W
√ √ −
00H
F0033H Pull-up resistor option register 3 PU3 R/W
√ √ −
00H
F0034H Pull-up resistor option register 4 PU4 R/W
√ √ −
01H
F0035H Pull-up resistor option register 5 PU5 R/W
√ √ −
00H
F0036H Pull-up resistor option register 6 PU6 R/W
√ √ −
00H
F0037H Pull-up resistor option register 7 PU7 R/W
√ √ −
00H
F0038H Pull-up resistor option register 8 PU8 R/W
√ √ −
00H
F0039H Pull-up resistor option register 9 PU9 R/W
√ √ −
00H
F003AH Pull-up resistor option register 10 PU10 R/W
√ √ −
00H
F003BH Pull-up resistor option register 11 PU11 R/W
√ √ −
00H
F003CH Pull-up resistor option register 12 PU12 R/W
√ √ −
00H
F003EH Pull-up resistor option register 14 PU14 R/W
√ √ −
00H
F0040H Port input mode register 0 PIM0 R/W
√ √ −
00H
F0041H Port input mode register 1 PIM1 R/W
√ √ −
00H
F0044H Port input mode register 4 PIM4 R/W
√ √ −
00H
F0045H Port input mode register 5 PIM5 R/W
√ √ −
00H
F0048H Port input mode register 8 PIM8 R/W
√ √ −
00H
F004EH Port input mode register 14 PIM14 R/W
√ √ −
00H
F0050H Port output mode register 0 POM0 R/W
√ √ −
00H
F0051H Port output mode register 1 POM1 R/W
√ √ −
00H
F0054H Port output mode register 4 POM4 R/W
√ √ −
00H
F0055H Port output mode register 5 POM5 R/W
√ √ −
00H
F0057H Port output mode register 7 POM7 R/W
√ √ −
00H
F0058H Port output mode register 8 POM8 R/W
√ √ −
00H
F0059H Port output mode register 9 POM9 R/W
√ √ −
00H
F005EH Port output mode register 14 POM14 R/W
√ √ −
00H
F0060H Port mode control register 0 PMC0 R/W
√ √ −
FFH
F0063H Port mode control register 3 PMC3 R/W
√ √ −
FFH
F006AH Port mode control register 10 PMC10 R/W
√ √ −
FFH
F006BH Port mode control register 11 PMC11 R/W
√ √ −
FFH
F006CH Port mode control register 12 PMC12 R/W
√ √ −
FFH
F006EH Port mode control register 14 PMC14 R/W
√ √ −
FFH
