RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 144
Sep 22, 2011
Table 3-6. Extended SFR (2nd SFR) List (2/8)
Manipulable Bit Range Address Special Function Register (SFR) Name Symbol R/W
1-bit 8-bit 16-bit
After Reset
F0070H Noise filter enable register 0 NFEN0 R/W
√ √ −
00H
F0071H Noise filter enable register 1 NFEN1 R/W
√ √ −
00H
F0072H Noise filter enable register 2 NFEN2 R/W
√ √ −
00H
F0073H Input switch control register ISC R/W
√ √ −
00H
F0074H Timer input select register 0 TIS0 R/W
− √ −
00H
F0076H A/D port configuration register ADPC R/W
− √ −
00H
F0077H Peripheral I/O redirection
register
PIOR R/W
− √ −
00H
F0078H Invalid memory access
detection control register
IAWCTL R/W
− √ −
00H
F007DH Global digital input disable
register
GDIDIS R/W
√ √ −
00H
F0090H Data flash control register DFLCTL R/W
√ √ −
00H
F00A0H High-speed on-chip oscillator
trimming register
HIOTRM R/W
− √ −
Note
F00A8H High-speed on-chip oscillator
frequency select register
HOCODIV R/W
− √ −
Undefined
F00E0H Multiplication/division data
register C (L)
MDCL R/W
− − √
0000H
F00E2H Multiplication/division data
register C (H)
MDCH R/W
− − √
0000H
F00E8H Multiplication/division control
register
MDUC R/W
√ √ −
00H
F00F0H Peripheral enable register 0 PER0 R/W
√ √ −
00H
F00F3H Operation speed mode control
register
OSMC R/W
− √ −
00H
F00F5H RAM parity error control register RPECTL R/W
√ √ −
00H
F00FEH BCD adjust result register BCDADJ R
− √ −
Undefined
F0100H SSR00L
− √
F0101H
Serial status register 00
−
SSR00 R
− −
√
0000H
F0102H SSR01L
− √
F0103H
Serial status register 01
−
SSR01 R
− −
√
0000H
F0104H SSR02L
− √
F0105H
Serial status register 02
−
SSR02 R
− −
√
0000H
F0106H SSR03L
− √
F0107H
Serial status register 03
−
SSR03 R
− −
√
0000H
F0108H SIR00L
− √
F0109H
Serial flag clear trigger register
00
−
SIR00 R/W
− −
√
0000H
F010AH SIR01L
− √
F010BH
Serial flag clear trigger register
01
−
SIR01 R/W
− −
√
0000H
F010CH SIR02L
− √
F010DH
Serial flag clear trigger register
02
−
SIR02 R/W
− −
√
0000H
F010EH SIR03L
− √
F010FH
Serial flag clear trigger register
03
−
SIR03 R/W
− −
√
0000H
Note The reset value differs for each chip.
