RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 200

Sep 22, 2011

Figure 4-26. Block Diagram of P47

P47/INTP2

PORT

WRPM

PU47

PM47

EVDD

P-ch

PU4

PM4

Output latch

(P47)

Selector

Alternate

function

Internal bus

P4: Port register 4

PU4: Pull-up resistor option register 4

PM4: Port mode register 4

RD: Read signal

WR××: Write signal
