RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 199

Sep 22, 2011

Figure 4-25. Block Diagram of P46

P46/TI05/TO05/INTP1

PORT

WRPM

PU46

PM46

EVDD

P-ch

PM4

PU4

Output latch

(P46)

Selector

Alternate

function

Alternate

function

Internal bus

P4: Port register 4

PU4: Pull-up resistor option register 4

PM4: Port mode register 4

RD: Read signal

WR××: Write signal

<R>
