RL78/G13
CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00
198
Sep 22, 2011
Figure 4-24. Blo
ck Diagram of P45
P45/SO01
WR
PU
WR
PORT
WR
PM
PU45
PM45
EV
DD
P-ch
PU4
PM4
P4
POM45
POM4
WR
POM
Output latch
(P45)
Selector
Alternate
function
Internal bus
RD
P4:
Port register 4
PU4:
Pull-u
p resistor option register 4
PM4:
Port mode register 4
POM4:
Port output mode register 4
RD: Read
sign
al
WR
××
: Write
signal
216
