RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 209

Sep 22, 2011

For example, figures 4-32 and 4-33 show block diagrams of port 6 for 128-pin products when PIOR = 00H

Figure 4-32. Block Diagram of P60 to P63

PORT

PM60 to PM63

PM6

Output latch

(P60 to P63)

Selector

Alternate

function

Alternate

function

Internal bus

P60/SCLA0,

P61/SDAA0,

P62/SCLA1,

P63/SDAA1

P6: Port register 6

PM6: Port mode register 6

RD: Read signal

WR××: Write signal

<R>
