RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 210

Sep 22, 2011

Figure 4-33. Block Diagram of P64 to P67

P64/TI10/TO10,

P65/TI11/TO11,

P66/TI12/TO12.

P67/TI13/TO13

PORT

PU64 to PU67

PM64 to PM67

P-ch

PM6

PU6

Output latch

(P64 to P67)

Selector

Alternate

function

Alternate

function

Internal bus

P6: Port register 6

PU6: Pull-up resistor option register 6

PM6: Port mode register 6

RD: Read signal

WR××: Write signal
