RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 225

Sep 22, 2011

Figure 4-44. Block Diagram of P96

P96/SI11/SDA11

PORT

PU96

P-ch

PU9

PM9

POM96

POM9

POM

PM96

Output latch

(P96)

Selector

Alternate

function

Alternate

function

Internal bus

P9: Port register 9

PU9: Pull-up resistor option register 9

PM9: Port mode register 9

POM9: Port output mode register 9

RD: Read signal

WR××: Write signal
