RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 228

Sep 22, 2011

For example, figures 4-46 to 4-48 show block diagrams of port 10.

Figure 4-46. Block Diagram of P100

P100/ANI20

PORT

PU100

PM100

P-ch

PU10

PM10

P10

A/D converter

PMC

PMC10

PMC100

Output latch

(P100)

Selector

Internal bus

P10: Port register 10

PU10: Pull-up resistor option register 10

PM10: Port mode register 10

PMC10: Port mode controlregister 10

RD: Read signal

WR××: Write signal
