RL78/G13 CHAPTER 4 PORT FUNCTIONS

R01UH0146EJ0100 Rev.1.00 229

Sep 22, 2011

Figure 4-47. Block Diagram of P101

P101

PORT

WRPM

EVDD

P-ch

PU10

PM10

P10

PM101

PU101

Output latch

(P101)

Selector

Internal bus

P10: Port register 10

PU10: Pull-up resistor option register 10

PM10: Port mode register 10

RD: Read signal

WR××: Write signal
