Figure 4-52. Block Diagram of P121 and P122

P122/X2/EXCLK

EXCLK, OSCSEL

CMC

OSCSEL

CMC

Clock generator

P121/X1

Internal bus

CMC: Clock operation mode control register

RD: Read signal
