RL78/G13 CHAPTER 4 PORT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 267
Sep 22, 2011
(8) Peripheral I/O redirection register (PIOR)
This register is used to specify whether to enable or disable the peripheral I/O redirect function.
This function is used to switch ports to which alternate functions are assigned.
The PIOR register can be set by an 8-bit memory manipulation instruction.
Reset signal generation sets this register to 00H.
