RL78/G13 CHAPTER 16 INTERRUPT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 835
Sep 22, 2011
Figure 16-3. Format of Interrupt Mask Flag Registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H, MK3L)(128-pin)
Address: FFFE4H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK0L PMK5 PMK4 PMK3 PMK2 PMK1 PMK0 LVIMK WDTIMK
Address: FFFE5H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK0H
SREMK0
TMMK01H
SRMK0
CSIMK01
IICMK01
STMK0
CSIMK00
IICMK00
DMAMK1 DMAMK0 SREMK2
TMMK11H
SRMK2
CSIMK21
IICMK21
STMK2
CSIMK20
IICMK20
Address: FFFE6H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK1L TMMK03 TMMK02 TMMK01 TMMK00 IICAMK0
SREMK1
TMMK03H
SRMK1
CSIMK11
IICMK11
STMK1
CSIMK10
IICMK10
Address: FFFE7H After reset: FFH R/W
Symbol <7> 6 5 4 <3> <2> <1> <0>
MK1H TMMK04 TMMK13
SRMK3
CSIMK31
IICMK31
STMK3
CSIMK30
IICMK30
KRMK ITMK RTCMK ADMK
Address: FFFD4H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK2L PMK10 PMK9 PMK8 PMK7 PMK6 TMMK07 TMMK06 TMMK05
Address: FFFD5H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK2H FLMK IICAMK1 MDMK
SREMK3
TMMK13H
TMMK12 TMMK11 TMMK10 PMK11
Address: FFFD6H After reset: FFH R/W
Symbol 7 6 <5> <4> <3> <2> <1> <0>
MK3L 1 1 TMMK17 TMMK16 TMMK15 TMMK14 DMAMK3 DMAMK2
XXMKX Interrupt servicing control
0 Interrupt servicing enabled
1 Interrupt servicing disabled
Caution The above is the bit layout for the 128-pin. The available bits differ depending on the product. For
details about the bits available for each product, see Table 16-2. Be sure to set bits that are not
available to 1.
