Renesas RL78/G13 User Manual

RL78/G13 CHAPTER 16 INTERRUPT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 837
Sep 22, 2011
Figure 16-4. Format of Priority Specification Flag Registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H,
PR03L, PR10L, PR10H, PR11L, PR11H, PR12L, PR12H, PR13L) (128-pin) (2/3)
Address: FFFEBH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR01H TMPR004 TMPR013
SRPR03
CSIPR031
IICPR031
STPR03
CSIPR030
IICPR030
KRPR0 ITPR0 RTCPR0 ADPR0
Address: FFFEFH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR11H TMPR104 TMPR113
SRPR13
CSIPR131
IICPR131
STPR13
CSIPR130
IICPR130
KRPR1 ITPR1 RTCPR1 ADPR1
Address: FFFD8H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR02L PPR010 PPR09 PPR08 PPR07 PPR06 TMPR007 TMPR006 TMPR005
Address: FFFDCH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR12L PPR110 PPR19 PPR18 PPR17 PPR16 TMPR107 TMPR106 TMPR105
Address: FFFD9H After reset: FFH R/W
Symbol <7> 6 <5> 4 3 2 1 <0>
PR02H FLPR0 IICAPR01 MDPR0
SREPR03
TMPR013H
TMPR012 TMPR011 TMPR010 PPR011
Address: FFFDDH After reset: FFH R/W
Symbol <7> 6 <5> 4 3 2 1 <0>
PR12H FLPR1 IICAPR11 MDPR1
SREPR13
TMPR113H
TMPR112 TMPR111 TMPR110 PPR111
