RL78/G13 CHAPTER 16 INTERRUPT FUNCTIONS
R01UH0146EJ0100 Rev.1.00 838
Sep 22, 2011
Figure 16-4. Format of Priority Specification Flag Registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H,
PR03L, PR10L, PR10H, PR11L, PR11H, PR12L, PR12H, PR13L) (128-pin) (3/3)
Address: FFFDAH After reset: FFH R/W
Symbol 7 6 <5> <4> <3> <2> <1> <0>
PR03L 1 1 TMPR017 TMPR016 TMPR015 TMPR014 DMAPR03 DMAPR02
Address: FFFDEH After reset: FFH R/W
Symbol 7 6 <5> <4> <3> <2> <1> <0>
PR13L 1 1 TMPR117 TMPR116 TMPR115 TMPR114 DMAPR13 DMAPR12
XXPR1X XXPR0X Priority level selection
0 0 Specify level 0 (high priority level)
0 1 Specify level 1
1 0 Specify level 2
1 1 Specify level 3 (low priority level)
Caution The above is the bit layout for the 128-pin. The available bits differ depending on the product. For
details about the bits available for each product, see Table 16-2. Be sure to set bits that are not
available to 1.
