ECODRIVE03-SGP-03VRS Diagnostic Message Descriptions 1-1
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
1 Diagnostic Message Descriptions
1.1 Overview of the Diagnostic Message Descriptions
Diagnostic Message Types
Each operational state of the drive will be characterized with a diagnostic
message.
Differentiations will be made between:
• Error diagnostic messages
• Warning diagnostic messages
• Command diagnostic messages
• Drive mode diagnostic messages
• Operation status
Construction of a Diagnostic Message
A diagnostic message consists of:
• Diagnostic message number
• Diagnostic text
F228 Excessive deviation
diagnostic message number
diagnostic message
Fig. 1-1: Diagnostic message with a diagnostic message number and text
For the example in the graphic, "F2" and "28" are shown alternately on the
H1-Display.
The control system can read out the diagnostic number in hexadecimal
form in parameter S-0-0390, Diagnostic message number.
In addition, the drive provides to the control system the diagnostic number
and diagnostic text as a string F228 Excessive deviation in parameter
S-0-0095, Diagnostic message.
