REXROTH ECODRIVE03 User Manual

ECODRIVE03-SGP-03VRS Description of Diagnostic Messages F… and E… 4-21
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
Note: The drive will not accept command values which lead out of
the permissible travel range. Entering these command values
in the drive controller will result in this error.
See also the functional description: "Travel Range Limits".
F644 Negative travel limit switch detected
The negative travel limit switch has been activated. The axis has been
brought to a standstill with the "Set velocity command value to zero" error
response.
Bit 2 of parameter P-0-0090, Travel limit parameter is set for "Exceeding
travel range as error", or a drive control command has been started (such
as the drive-controlled homing procedure). with the limit switch already
actuated.
Cause:
The negative travel limit switch has been activated.
Remedy:
1. Reset the error.
2. Turn the power supply on again.
3. Move the axis into the permissible travel range.
Note: The drive will not accept command values which lead out of
the permissible travel range. Entering these command values
in the drive controller will result in this error.
See also the functional description: "Travel Range Limits".
F811 Commutation offset could not be determined
The automatic commutation adjustment has tried to determine the
commutation offset. This has failed.
Cause:
1. The motor could not move freely.
2. Direction of movement of the encoder is incorrect.
3. Incorrect polarity of the motor.
4. Axis mechanically blocked.
5. Brake applied.
6. Axis is in endstop position.
Remedy:
1. Check mechanically whether the motor can be moved.
2. Check the encoder. Invert the direction of movement of the encoder,
if necessary.
3. Check motor connection to the controller.
4. Release mechanical blocking.
5. Check brake and control signals. The brake must be released
immediately when the controller enable signal is set.
6. Make sure the axis does not remain in endstop position.
See also functional description: "Determining the commutation offset"
