1-2 Diagnostic Message Descriptions ECODRIVE03-SGP-03VRS
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
H1-Display
The H1-Display serves as an optical display of the diagnostic message on
the drive.
Barcode
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
H1
S1
S3
S2
Barcode
Typenschild
123456789
123456789
1234
1234
11121314 15161718
5678
1234
1234
5678
DKC
H1-Display
FA5047f1.fh7
Fig. 1-2: H1-Display
The diagnostic number appears on this two-positional seven-segment
display. The image can be seen on the figure "Priority-dependent
diagnostic message display" (Fig. 1-3).
This display quickly shows the current operation status without the use of
a communications interface.
The operating mode cannot be seen from the H1-Display. If the drive
follows the operating mode and no command was activated, then the
symbol "AF" appears on the display.
