5-4 Description of Diagnostic Messages B…; C…, D… and A ECODRIVE03-SGP-03VRS
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
Remedy:
A list of the invalid parameters can be seen in parameter S-0-0021, List
of invalid op. data for comm. ph. 2. The invalid parameters must be
rewritten with values between the respective min. and the max. value to
be correct.
See also the functional description: "S-0-0127, C100 Communication
phase 3 transition check"
C104 Config. IDN for MDT not configurable
Cause:
Telegram type 7 was set in parameter S-0-0015, Telegram type
parameter. Parameters which are missing in S-0-0188, List of
configurable data in MDT are kept in S-0-0024, Configuration list for
the master data telegram.
Remedy:
• set preferred telegram (telegram type = 0..6 )
• You must either set a priority telegram (Telegram type = 0..6) or
provide S-0-0024, Config. list of master data telegram with
parameters. These parameters are also contained in S-0-0188, List of
configurable data in the MDT.
Note: List parameters only allowed in multiplex channel.
See also the function description: "Configuration of telegram contents"
C105 Configurated length > max. length for MDT
Cause:
Telegram type 7 was set in parameter S-0-0015, Telegram type
parameter. The length of the configured data in MDT, which is
determined by S-0-0024, Configurations list of the master data
telegram, exceeds the maximum permissible length S-0-0186, Length of
the configurable data record in the MDT.
Remedy:
• set preferred telegram (telegram type = 0..6 )
• number of configured parameters in MDT (S-0-0024) must be
decreased
See also the functional description: "Configuration of telegram contents"
C106 Config. IDN for AT not configurable
Cause:
Telegram type 7 was set in parameter S-0-0015, Telegram type
parameter. Parameters which are not contained in S-0-0187, List of
configurable data in AT can be seen in S-0-0016, Custom amplifier
telegram configuration list.
