ECODRIVE03-SGP-03VRS Description of Diagnostic Messages F… and E… 4-27
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
4.2 Warning Diagnostic Messages E…
Many areas are monitored in connection with operating modes and
parameter settings. As a result, if a state is discovered which is still
allowed by the order of operation, but in continuous operation generates
an error and thereafter leads to shutdown of the drive, a warning will be
generated in the case where this state appears again.
Warning Classes
Warnings can be separated into 2 classes. They differentiate if the drive
will perform an automatic response with the appearance of a warning.
Warning class Diagnostic
message
Drive reaction
With drive reaction E8xx Drive stop
Without drive reaction E2xx --
Fig. 4-6: Division of the warning class
Warnings can not be externally deleted.
Warnings do not lead to an
automatic shutdown.
The warning class is evident
from the diagnostic message.
