2-2 Important directions for use ECODRIVE03-SGP-03VRS
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
Areas of use and application
The BTV30.2 is a PC-based user and visualization terminal into which
one or several NC controls with PLC or one or more stand-alone PLCs
can be mounted. The BTV30.2 terminal made by Rexroth Indramat is
designed for use in the following cases:
• as a user, visualization and programming terminal with integral control
hardware in a stand-alone machine,
• as a user, visualization and programming terminal for connected
RECO controls,
• and as a special „T“ design, a terminal without PC for a second user
station within an installation that is spatially spread apart.
Note: The BTV30.2 may only be used with the accessories and parts
specified in this document. If a component has not been
specifically named, then it may not be either mounted or
connected. The same applies to cables and lines.
Operation is only permitted in the specified configurations and
combinations of components using the software and firmware
as specified in the relevant function descriptions.
The machine user and visualization terminal is designed for control tasks
in an installation with multiple axes.
Available for an application-specific use of the terminals are unit types
with differing drive power and different interfaces.
Typical areas of application of a BTV30.2 are:
• lathes
• milling machines and
• machining centers.
The BTV30.2 may only be operated under the assembly, installation and
ambient conditions as described here (temperature, system of protection,
humidity, EMC requirements, etc.) and in the position specified.
2.2 Inappropriate use
Using the motors outside of the above-referenced areas of application or
under operating conditions other than described in the document and the
technical data specified is defined as “inappropriate use".
The terminals may not be used if
• they are subject to operating conditions that do not meet the above
specified ambient conditions. This includes, for example, operation
under water, in the case of extreme temperature fluctuations or
extreme maximum temperatures or if
• Rexroth Indramat has not specifically released them for that intended
purpose. Please note the specifications outlined in the general Safety
Instructions!
