ECODRIVE03-SGP-03VRS Description of Diagnostic Messages F… and E… 4-3
DOK-ECODR3-SGP-03VRS**-WA01-EN-P
Remedy:
Command C700 Basic Load or press the S1 button.
See also the functional description: "Automatic execution of the load
default feature".
F209 PL Load parameter default values
After replacing the firmware version, the drive displays “PL”, if the
parameters have been changed in regards to the old product. By pressing
the S1 button on the drive controller or by starting the command “load
basic parameters”, all the parameters will be erased and restored with the
default (initial) values.
Cause:
The firmware has been exchanged; the number of parameters in
comparison to the old product has changed.
Remedy:
Press S1 button on the drive controller, and all the parameters will be
erased and restored with the factory preset default values
WARNING
⇒ This overwrites all parameters and positioning blocks.
See also the functional description: "Basic parameter block".
F217 Blower not connected
In the case of the 100 A and 200 A drive controllers, the blower must
always be connected.
Cause:
• blower has not been connected at all or incorrectly
Remedy:
• connect or replace blower
F218 Amplifier overtemperature shutdown
The temperature of the amplifier’s heatsink is monitored. If the heatsink is
too hot, the drive will power down in order to protect against damage.
Cause:
1. Ambient temperature is too high. The specified performance data are
valid up to an ambient temperature of 45°C.
2. The amplifier’s heatsink is dirty.
3. Air flow is prevented by other assembly parts or the control cabinet
assembly.
4. Blower defective.
5. E219: Sensor defective appears prior to shutdown of unit
