Ricoh A-C4 - Installation Procedure; Installation Requirements

20 June 2005 INSTALLATION REQUIREMENTS
1-1
Installation
1. INSTALLATION PROCEDURE
CAUTION
Never turn off the main power switch when the power LED is lit or flashing.
To avoid damaging the hard disk or memory, press the operation power
switch to switch the power off, wait for the power LED to go off, and then
switch the main power switch off.
NOTE: The main power LED lights or flashes while the platen cover or ARDF is
open, while the main machine is communicating with a facsimile or the
network server, or while the machine is accessing the hard disk or memory
for reading or writing data.
1.1 INSTALLATION REQUIREMENTS

CAUTION
B135I016.WMF
“Rating Voltage of Output
Connector, Max. DC24 V”
LCT
“Rating Voltage of Output
Connector, Max. DC24 V”
Finisher
“Rating Voltage of Output
Connector, Max. DC24 V”
Scanner Unit
“Rating Voltage of Output
Connector, Max. DC24 V”
ARDF
