20 June 2005 1-BIN TRAY UNIT INSTALLATION (B544)
1-25
Installation
1.5 1-BIN TRAY UNIT INSTALLATION (B544)
1.5.1 ACCESSORY CHECK
Check the quantity and condition of the accessories in the box against the following
list:
Description Q’ty
1. Ground Bracket...................................................................... 1
2. Connector Cover.................................................................... 1
3. Base Cover ............................................................................ 1
4. Arm Cover.............................................................................. 1
5. Copy Tray .............................................................................. 1
6. Mylar Strip.............................................................................. 2
7. Stepped Screw – M3 x 8........................................................ 5
8. Screw –M3 x 8 ....................................................................... 2
9. Screw – M4 x 7 ...................................................................... 1
10. Tapping Screw – M3 x 6 ........................................................ 2
11. Tapping Screw – M3 x 14 ...................................................... 1
12. Tapping Screw – M3 x 8 ........................................................ 1
13. Installation Procedure ............................................................ 1
