Ricoh A-C4 - Test Pattern Table: SP2-902-3 Printing Test Patterns

SERVICE PROGRAM MODE TABLES 20 June 2005
5-118
Test Pattern Table: SP2-902-3 Printing Test Patterns
No. Test Pattern
0 None
1 Vertical Line (1-dot)
2 Horizontal Line (1-dot)
3 Vertical Line (2-dot)
4 Horizontal Line (2-dot)
5 Grid Pattern (1-dot)
6 Independent Pattern (1-dot)
7 Independent Pattern (2-dot)
8 Full Dot Pattern
9 Black Band
10 Trimming Area
11 Argyle Pattern
12 Hounds Tooth Check (2-Dot Horizontal)
13 Checker Flag Pattern
14 Black Band (Vertical)
15 Independent Pattern (4-Dot)
16 Horizontal Line (1-Dot) (Reversed LD1, LD2)
17 Grid Pattern (1-dot pair) (Reversed LD1, LD2)
18 Independent Pattern (1-dot) (Reversed LD1, LD2)
19 Grayscale (Horizontal)
20 Grayscale (Vertical)
21 Grayscale (Horizonta/Vertical)
22 Grayscale (Grid)
23 Grayscale (Horizontal Margin)
24 Grayscale (Vertical Margin)
25 Grayscale (Vertical/Horizontal Margin)
26 White Pattern
27 Grid (1-dot pair) (OR Outside Data 1)
