Removing Jammed Paper
107
7
A Press the key of the section from where you want to remove the jammed pa-
per.
B After each step is complete, press [Next]. To go back to the previous step,
press [Previous].
C When the jammed paper is entirely removed, restore the machine to its
original state.
Note
❒ More than one misfeed may be indicated. When this happens, check all the
areas indicated.
Reference
p.108 “When A Is lit”
p.108 “When B Is lit”
p.108 “When C Is lit”
p.109 “When D Is lit”
p.109 “When E Is lit”
p.110 “When F Is lit”
p.111 “When N Is Lit”
p.112 “When P Is Lit”
p.113 “When Q Is lit”
p.114 “When R Is Lit”
p.117 “When W Is lit”
p.117 “When U Is lit”
