Copier Functions
57
2
Directional Size Magnification (inch)
A suitable reproduction ratio is automatically selected when you enter the hori-
zontal and vertical lengths of the original and copy image you require.
A Horizontal original size: A mm (inch)
B Vertical original size: B mm (inch)
C Horizontal copy size: a mm (inch)
D Vertical copy size: b mm (inch)
Measure and specify the lengths of the original and copy by comparing “A” with
“a” and “B” with “b”.
A Press [Reduce / Enlarge].
B Press [Dir. Size Mag. Inch].
C Enter the horizontal size of the original with the number keys, and then
press the {q} key.
You can enter sizes between 1 to 9999 mm (0.1" to 99.9") in 1 mm (0.1") steps.
D Enter the horizontal size of the copy with the number keys, and then press
the {q} key.
E Enter the vertical size of the original with the number keys, and then press
the {q} key.
You can enter sizes between 1 to 999 mm (0.1" to 99.9") in 1 mm (0.1") steps.
ATY051S
To Next Page
