016 Make HDD Debug
017 Make SD Debug
5858
[Debug Save When] *CTL -
These SPs select the content of the debugging information to be saved to the destination
selected by SP5857-002.
SP5858-3 stores one SC specified by number. Refer to Section 4 for a list of SC error
codes.
001
Engine SC Error
(0:OFF 1:ON)
Turns on/off the debug save for SC codes generated by
printer engine errors.
[0 or 1 / 0 / 1/ step]
002
Controller SC Error
(0:OFF 1:ON)
Turns on/off the debug save for SC codes generated by
GW controller errors.
[0 or 1 / 0 / 1/ step]
003 Any SC Error [0 to 65535 / 0 / 1 /step]
004 Jam(0:OFF 1:ON)
Turns on/off the debug save for jam errors.
[0 or 1 / 0 / 1/ step]
5859 [Debug Save Key No.] *CTL -
001 Key 1
These SPs allow you to set up to 10 keys for log files for
functions that use common memory on the controller
board.
[–9999999 to 9999999 / 0 / – ]
002 Key 2
003 Key 3
004 Key 4
005 Key 5
006 Key 6
007 Key 7
008 Key 8
009 Key 9
010 Key 10
Main SP Tables-5
329
