5919 [State Of Encryption] *CTL [0 or 1 / 0 / – ]
001
5967 [Copy Server Set Function] *CTL 0: ON, 1: OFF
001
Enables and disables the document server. This is a security measure that prevents image
data from being left in the temporary area of the HDD. After changing this setting, you
must switch the main switch off and on to enable the new setting.
5970 [Debug Serial Output] *CTL [0 or 1 / 0 / – ]
001
5973
[User Stamp Registration]
Executes the user stamp registration in the initial copy setting.
001 Frame deletion setting *CTL
[0 to 3 / 0 / 1/step]
The following settings can be selectable:
• Stamp image ID
•
Width to the main scan direction
• Width to the sub scan direction
5974
[Cherry Server]
Specifies which version of ScanRouter, “Lite” or “Full”, is installed.
001 (0:Light 1:Full) *CTL [0 or 1 / 0 / – ]
5985
[Device Setting]
Enables/disables the on-board device.
3. SP Mode Tables
336
