Always move the printer horizontally. Turning the printer sideways or tilting it backward or forward
while moving will result in toner leakage.
Do not put the printer on an unstable or sloped surface.
Be sure to move the printer horizontally. Moving the printer up and down may cause toner to scatter.
1. Lift the paper tray slightly, and then pull it out until it stops.
BMU017S
2. Lift the front side of the tray, and then pull it out of the printer.
BMU018S
3. If the optional duplex unit is attached, push down the lever on the right side of the duplex
unit ( ), and then pull it out until it stops ( ).
BMU077S
Replacing the Maintenance Kit
135
6
