Ricoh CL4000DN Quick Installation Guide

4. Push the under board levers ( ), and then pull the duplex unit out of the printer ( ).
BMU078S
5. Move the printer to the edge of a sturdy and stable table or desk.
BMU067S
6. Slide the green lock lever to the left ( ), and then remove the paper feed roller ( ).
BMU068S
6. Replacing Consumables and Maintenance Kit
136
6
