Ricoh CL4000DN Quick Installation Guide

1. Open the rear cover.
BMU034S
2. Lower the rear cover until it is horizontal, and then pull it away.
BMU038S
3. If the optional duplex unit is attached, push down the lever on the right side of the duplex
unit ( ), and then pull it out until it stops ( ).
BMU077S
Replacing the Maintenance Kit
139
6
