4. Push the under board levers ( ), and then pull the duplex unit out of the printer ( ).
BMU078S
5. Lift the lock levers of the fusing unit as shown in the illustration.
BMU070S
6. Pull the fusing unit out.
BMU071S
6. Replacing Consumables and Maintenance Kit
140
6
